Suction Air Compressor Nebulizer Machine for Medical/Home use

MOQ:
Product name:
Type:
Power Source:
Properties:
Colour:
Availability:
Quantity:
  • CNME071123
  • CNMEDITECH

Suction Air Compressor Nebulizer Machine for Medical/Home use

800-1123

Compressor Nebulizer Specification:

Product name

Suction Air Compressor Nebulizer

Atomization rate

≥ 0.2mL /min

Median particle size

3.5μm±25%

Rated voltage

220V/50Hz

Noise

≤65 dB (one meter away from the machine)

Gas flow

≥6.7L/Min

Liter flow range

6.7lpm

Maximum nebulization rate

0.25mL/min

Sound level

w65dB(A)

Particle size

0.5-10 pm

Operation pressure range

9.5-19psi

Compressor pressure range

22-58psi

Housing Material

ABS

Size

196*104*145mm



Features:

1.Professional medical grade

2.One key operation/Oi-free piston pump

3.Fast, efficient operation. with a nebulization rate of 0.25mL/minute and particles as small as 3.5um .

4.Adopt the latest efficient oil-free compression pump

5.Low noise. runs at less than 65 dB.

6.Affordable and efficient alternative.



Operation method:

1. Rotate the atomizing cup clockwise (If it is threaded connection type, please rotate it counterclockwise)

2. Put the liquid into the nebulizer cup. (The amount of atomizing liquid shall not exceed the maximum scale marked on the cup body)

Cup body mark above maximum scale)

3. Insert the lid into the cup and turn the lid counterclockwise (for  threaded connection type, please turn it clockwise)

4. Connect the oxygen catheter to the nebulizer cup

5. Connect the mouthpiece to the nebulizer cup

6. Connect the oxygen catheter to the gas outlet of the nebulizer

7.Turn on the power supply, turn on the switch, and start nebulization

800-1123-3

Package included:

800-1123-5

Package details

50*24.5*48cm, G.W. 13kg
