Sterile Disposable A.V. Fistula Needle For Dialysis

The safe and gentle vascular access is an important criteria for users and patients in efficient and successful dialysis treatment. Using the optimum cannulation procedures CN MEDITECH AV Fistula Needle reduces the chances of trauma during vascular access.
Size:
Material:
MOQ:
Availability:
Quantity:
  • CNME040404

  • CNMEDITECH

Sterile Disposable A.V. Fistula Needle For Dialysis

A.V. fistula needle

Features:


*Safety AV Fistula Needle allows venous and arterial access for patients undergoing hemodialysis

*Ultra-thin wall stainless steel needle (with or without back-eye) siliconized on both internal and external surfaces:

*Provides optimum penetration profile

*Minimizes pain during insertion

*Maximizes smooth, laminar flow

*USP Class VI soft, kink-resistant tubing made from medical-grade PVC

*Rotating, color-coded wings facilitate flipping of needle while allowing for easy gripping and fixation

*Orientation dot on needle hub enables precise maneuvering of bevel

*Luer has universal 6% taper to allow smooth connection with standard bloodline sets

*Available in single pack or twin-pack for better use of space

*The device AVF set is comprised with a needle safety guard (safety clip)* over the tube towards the needle tip, the needle guard completely encloses the needle and cannot be moved any further.

*Non-pyrogenic, Sterilized by Ethylene Oxide.


Specifications:

Diameter

Wing

Needle length(mm)

Tube length(mm)

14G

Fixed

25mm±2.0mm

300±20mm

15G

Fixed

25mm±2.0mm

300±20mm

16G

Fixed

25mm±2.0mm

300±20mm

17G

Fixed

25mm±2.0mm

300±20mm

14G

Fixed

32mm±2.0mm

300±20mm

15G

Fixed

32mm±2.0mm

300±20mm

16G

Fixed

32mm±2.0mm

300±20mm

17G

Rotatable

32mm±2.0mm

300±20mm

14G

Rotatable

25mm±2.0mm

300±20mm

15G

Rotatable

25mm±2.0mm

300±20mm

16G

Rotatable

25mm±2.0mm

300±20mm

17G

Rotatable

25mm±2.0mm

300±20mm

14G

Rotatable

32mm±2.0mm

300±20mm

15G

Rotatable

32mm±2.0mm

300±20mm

16G

Rotatable

32mm±2.0mm

300±20mm

17G

Rotatable

32mm±2.0mm

300±20mm
