CNME040404
CNMEDITECH
Sterile Disposable A.V. Fistula Needle For Dialysis
Features:
*Safety AV Fistula Needle allows venous and arterial access for patients undergoing hemodialysis
*Ultra-thin wall stainless steel needle (with or without back-eye) siliconized on both internal and external surfaces
*Provides optimum penetration profile
*Minimizes pain during insertion
*Maximizes smooth, laminar flow
*USP Class VI soft, kink-resistant tubing made from medical-grade PVC
*Rotating, color-coded wings facilitate flipping of needle while allowing for easy gripping and fixation
*Orientation dot on needle hub enables precise maneuvering of bevel
*Luer has universal 6% taper to allow smooth connection with standard bloodline sets
*Available in single pack or twin-pack for better use of space
*The device AVF set is comprised with a needle safety guard (safety clip)* over the tube towards the needle tip, the needle guard completely encloses the needle and cannot be moved any further.
*Non-pyrogenic, Sterilized by Ethylene Oxide.
Specifications:
| Diameter | Wing | Needle length(mm) | Tube length(mm) |
| 14G | Fixed | 25mm±2.0mm | 300±20mm |
| 15G | Fixed | 25mm±2.0mm | 300±20mm |
| 16G | Fixed | 25mm±2.0mm | 300±20mm |
| 17G | Fixed | 25mm±2.0mm | 300±20mm |
| 14G | Fixed | 32mm±2.0mm | 300±20mm |
| 15G | Fixed | 32mm±2.0mm | 300±20mm |
| 16G | Fixed | 32mm±2.0mm | 300±20mm |
| 17G | Rotatable | 32mm±2.0mm | 300±20mm |
| 14G | Rotatable | 25mm±2.0mm | 300±20mm |
| 15G | Rotatable | 25mm±2.0mm | 300±20mm |
| 16G | Rotatable | 25mm±2.0mm | 300±20mm |
| 17G | Rotatable | 25mm±2.0mm | 300±20mm |
| 14G | Rotatable | 32mm±2.0mm | 300±20mm |
| 15G | Rotatable | 32mm±2.0mm | 300±20mm |
| 16G | Rotatable | 32mm±2.0mm | 300±20mm |
| 17G | Rotatable | 32mm±2.0mm | 300±20mm |
